Page Metadata


Status: ✅ Accepted
Date: 2026-03-06

Unique Release Name

Context and Problem Statement

As a CPaaS provider we need to manage addons across a wide range of Kubernetes Clusters.

Based on external factors we want to match profiles, e.g.: - There is a Release for Kyverno V1 and it supports K8s >1.25. - There is another Release for Kyverno V2 and it supports K8s >1.33.

We now have two profiles matching our Clusters with K8s version >1.33 and others.

Kyverno should only be rolled out exactly once with higher versions taking precedence and allow in-place upgrades.

Without conflict resolution, both profiles match the same Target and both Kyverno releases are deployed — causing a duplicate installation:

flowchart LR
    comp[Component Kyverno]
    cv1[ComponentVersion 1.0.0]
    cv2[ComponentVersion 2.0.0]
    rel1[Release 1]
    rel2[Release 2]
    p1["Profile 1\nk8s > 1.25"]
    p2["Profile 2\nk8s > 1.33"]
    target["Target\nk8s 1.35"]

    subgraph cluster["k8s Cluster 💥"]
        direction TB
        k1[Kyverno 1.0.0]
        k2[Kyverno 2.0.0]
    end

    comp --> cv1 --> rel1 --> p1
    comp --> cv2 --> rel2 --> p2
    p1 -->|matches| target
    p2 -->|matches| target
    target -->|renders both| k1
    target -->|renders both| k2
Hold "Alt" / "Option" to enable pan & zoom

Decision Outcome

  • Release.Spec.UniqueName is a logical identifier that groups releases representing the same component. When multiple releases share a uniqueName, only one is deployed per Target.
    • If not set, the Target controller uses the parent Component name (from the referenced ComponentVersion) as the effective deduplication key at reconcile time. The field itself remains empty in storage.
    • Immutable once set.
  • Releases carry a Priority field. When multiple releases share the same uniqueName on a Target, the one with the highest priority wins.
    • If priorities are equal, the conflict is broken deterministically by the namespace-qualified ReleaseBinding name in ascending alphabetical order.
  • Releases can define AntiAffinity rules (label selectors). If another Release already accepted for a Target matches the selector — or vice versa — the lower-priority Release is excluded.
  • The resolver runs in the Target controller after all ReleaseBindings are collected and before any RenderTask is created.
  • The uniqueName doubles as the identity of a release within a Target's bootstrap chart: it is the map key under which the release is registered in the bootstrap input (and thus the suffix of the generated FluxCD resource names). The Kubernetes Release object name is not suitable here because it is not unique across namespaces — with cross-namespace ReleaseBindings, two namespaces can each define a my-release, and keying on the object name would let one silently overwrite the other in the bootstrap. Keying on uniqueName is safe because the resolver guarantees it is unique among accepted releases.

Solution

Deduplication by priority

Two releases share uniqueName: kyverno. The Target controller keeps only the higher-priority one:

flowchart LR
    comp[Component Kyverno]
    cv1[ComponentVersion 1.0.0]
    cv2[ComponentVersion 2.0.0]
    rel1["Release 1\nuniqueName: kyverno\npriority: 1"]
    rel2["Release 2\nuniqueName: kyverno\npriority: 2"]
    p1["Profile 1\nk8s > 1.25"]
    p2["Profile 2\nk8s > 1.33"]
    target["Target\nk8s 1.35"]
    resolver{{"Release Resolver\nkyverno → Release 2 wins"}}
    rt[RenderTask]

    subgraph cluster["k8s Cluster ✓"]
        k[Kyverno 2.0.0]
    end

    comp --> cv1 --> rel1 --> p1
    comp --> cv2 --> rel2 --> p2
    p1 -->|matches| target
    p2 -->|matches| target
    target --> resolver
    resolver -->|accepted| rt --> k
    rel1 -.->|filtered: lower priority| resolver
Hold "Alt" / "Option" to enable pan & zoom

Anti-affinity

A Release can declare that it must not be co-deployed with releases matching a given label selector. The resolver enforces this bidirectionally:

flowchart LR
    istio["Release Istio\nlabels: category=service-mesh\npriority: 10"]
    linkerd["Release Linkerd\nantiAffinity: category=service-mesh\npriority: 5"]
    target[Target]
    resolver{{"Release Resolver"}}
    rt[RenderTask]

    subgraph cluster["k8s Cluster ✓"]
        i[Istio]
    end

    istio -->|bound via Profile| target
    linkerd -->|bound via Profile| target
    target --> resolver
    resolver -->|accepted: higher priority| rt --> i
    linkerd -.->|filtered: anti-affinity conflict with Istio| resolver
Hold "Alt" / "Option" to enable pan & zoom
